Advantech - Advantech ASMB-815

Motherboard - ATX - LGA3647-P0 Socket - C621 Chipset - 2 x Gigabit LAN - onboard graphics

Advantech
ASMB-815I-00A1E
N/A
N/A
N/A
New

Price: $837.00

MSRP: $837.00
Total Available: 0

Product Description

Additional Details

Specifications

Main Specifications
Product Description Advantech ASMB-815 - motherboard - ATX - LGA3647-P0 Socket - C621
Product Type Motherboard - ATX
Chipset Type Intel C621
Processor Socket 1 x LGA3647-P0 Socket
Max RAM Size 192 GB
RAM Supported 6 DIMM slots - DDR4, ECC, registered
Storage Ports 8 x SATA-600, 1 x M.2
Graphics ASPEED AST2500
LAN 2 x Gigabit Ethernet
General
Product Type Motherboard - ATX
Chipset Type Intel C621
Processor Socket LGA3647-P0 Socket
Max Processors Qty 1
Expansion / Connectivity
Expansion Slots 1 x CPU ¦ 6 x DIMM 288-pin ¦ 1 x PCIe x1 ¦ 1 x PCIe x4 ¦ 3 x PCIe x8 ¦ 2 x PCIe x16
RAID Features Software RAID 0/ 1 / 10 / 5
Interfaces 2 x USB 2.0 ¦ 4 x USB 3.0 ¦ 1 x management ¦ 1 x serial ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x VGA
Internal Interfaces 1 x serial - header ¦ 4 x USB 2.0 - header ¦ 2 x USB 3.0 - header ¦ 1 x USB 2.0 - Type A ¦ 1 x audio - header ¦ 2 x PS/2
Miscellaneous
Width 12 in
Depth 9.6 in
Features
BIOS Type AMI
BIOS Features UEFI BIOS
LAN
Network Controller 2 x Intel I210AT
Network Interfaces 2 x Gigabit Ethernet
Graphics
Graphics Controller ASPEED AST2500
Supported RAM
Max Size 192 GB
Technology DDR4
Bus Clock 2400 MHz, 2133 MHz
Supported RAM Integrity Check ECC
Registered or Buffered Registered
